Touchscreen adds Pixel Eyes in-cell capacitive technology
LCD modules from KOE now include display modules with projected capacitive (PCap) and Pixel Eyes in-cell capacitive touchscreens.
Pixel Eyes in-cell capacitive touchscreen technology features on the new 8.8-inch TX22D200VM0BVA (1280 x 720 pixels) and 10.2-inch TX26D208VM0AVA (1920 x 1080 pixels) display modules.
Pixel Eyes is an automotive grade-approved technology which ensures high levels of quality assurance and exemplary manufacturing standards are achieved, says the company.
KOE’s proprietary Pixel Eyes in-cell technology integrates projected capacitive touch panel functionality into the LCD cell. The Rx (receiver) function is incorporated into the shielding layer on the colour filter substrate, and the Tx (transmitter) function is incorporated into the common electrode on the TFT substrate. Pixel Eyes touch technology enables thinner and lighter display modules to be designed and manufactured.
Other PCap touchscreen modules available from KOE measure 6.3, 7.0, 8.0, 10.1, 10.4 and 12.3-inch display modules with resolutions ranging from 800 x 280 pixels to 1920 x 1200 pixels.
The key features of KOE projected capacitive and Pixel Eyes in-cell touchscreen displays include accurate and flexible touch interactions and support for multiple (up to 10) touch points. The modules remain fully functional under up to 8.0mm protective cover glass and are water- and moisture-resistance. Touch functionality is maintained with wet fingers or gloves, adds KOE. There is also an optional optical bonded cover glass.
KOE’s PCap and Pixel Eyes touchscreen display modules are suitable for graphical user interface (GUI) applications which require a robust, reliable touch interface offering precise and flexible gesture interaction.
The use of optical bonding technology allows a variety of surface treatments such as anti-glare (AG), anti-reflective (AR), anti-fingerprint and scratch-resistant hard coatings to be used. Optical bonding can also significantly improve the optical performance of the display, says KOE. A TFT display featuring an optically bonded cover glass and surface coating can reduce reflections to less than 0.2 per cent by scattering and absorbing ambient light.
KOE is able to provide full-custom and semi-custom PCap touchscreen display module solutions, including unique cover glass designs, surface treatment and printing, and optical bonding requirements to meet the needs of individual applications and design projects.
The range of KOE PCap and Pixel Eyes TFT display modules are available immediately from KOE’s sales channel and distribution partners.
