COM Express Type 6 module supports up to six-core Intel processors

The latest COM Express Type 6 modules from Adlink fulfils the needs of even the most performance-demanding applications, says the company. The Express-CF modules feature the Intel Xeon E-2100M and eighth generation Intel Core processors (formerly codenamed Coffee Lake H) with up to six cores (Hexa) and up to 48Gbyte memory capacity. The Express-CF is suitable for demanding applications such as image processing and analysis, 4K high speed video encoding and streaming, medical ultrasound and predictive traffic analysis.

Express-CF modules are the first Type 6 modules to support both Xeon and Core i7 Hexa-core CPUs. The Hexa-core processors support up to 12 threads and a turbo boost of up to 4.4GHz. Compared to earlier mobile quad-core Xeon and Core i7 CPUs, the additional two cores of the Hexa-core CPUs results in more than 25 per cent performance boost at no significant cost increase, reports the company.

The Express-CF provides standard support for up to 48Gbyte non-ECC DDR4 in three SO-DIMMs (two on the top, one on the bottom), while still fully complying with PICMG COM.0 mechanical specifications. Modules equipped with the Xeon Hexa-core processor support both ECC and non-ECC SODIMMs.

With integrated Intel UHD Graphics 630, the Express-CF supports up to three independent 4K displays via DisplayPort, HDMI, DVI and LVDS. Adlink also offers either eDP or analogue VGA as build options by customer request. Additionally, the Express-CF supports Intel Optane memory and NVMe SSDs through high speed PCIe x4 Gen3 interfaces.

Adlink Technology provides hardware, connectivity, and software to form complete IIoT solutions for industrial automation and manufacturing, networking and communications, healthcare, infotainment and retail, transportation, and government and defence industries. IIoT solutions can include embedded building blocks and intelligent computing platforms, edge platforms, data connectivity and extraction devices, secure software for data movement, and micro services to monitor, manage, and analyse data-streaming assets and devices.
